EE/EF型磁芯
EE/EF型磁芯
| |||||||||||||
| Fig.1 | |||||||||||||
| 规格 Type | 图形Fig. | 尺寸Dimensions(mm) | 有效参数Effective parameter | 电感系数AL(nH/N2) | 重量(克/付) | ||||||||
| A | B | C尺寸可调 | D | E | F | Ae(mm2) | Le(mm) | Ve(mm3) | BP44 | BP95 | Weight(g/set) | ||
| EF13.5/6/4 | 1 | 13.50±0.30 | 6.25±0.20 | 3.50±0.20 | 3.50±0.20 | 9.8 min | 4.50±0.20 | 12.14 | 30.05 | 364.50 | 800±25% | 1000±25% | 2.40 |
| EF13.5/7/7.2 | 1 | 13.50±0.30 | 7.20±0.20 | 7.20±0.20 | 3.50±0.20 | 9.8 min | 5.20±0.20 | 25.50 | 33.20 | 846.60 | 1600±25% | 2000±25% | 5.00 |
| EF13.6/5/12-1 | 1 | 13.60±0.30 | 5.40±0.20 | 11.95±0.20 | 3.00±0.20 | 10.0 min | 3.90±0.20 | 36.70 | 27.30 | 1001.91 | 2000±25% | 3000±25% | 6.15 |
| EF14/7/4 | 1 | 13.70±0.30 | 6.80±0.20 | 3.50±0.20 | 3.50±0.20 | 10.10 min | 4.80±0.20 | 12.40 | 31.80 | 394.32 | 800±25% | 1000±25% | 2.35 |
| EE13/6/6D | 1 | 13.1±0.30 | 6.25±0.20 | 6.1±0.20 | 2.7±0.20 | 10.0 min | 4.85±0.20 | 16.90 | 31.40 | 530.66 | 1100±25% | 1300±25% | 3.37 |
| EE13/6/9.8D | 1 | 13.1±0.30 | 6.25±0.20 | 9.8±0.20 | 2.7±0.20 | 10.0 min | 4.85±0.20 | 26.75 | 31.40 | 839.95 | 1700±25% | 2050±25% | 5.50 |
| EE13/7/6B | 1 | 13.1±0.30 | 6.80±0.20 | 6.1±0.20 | 2.7±0.20 | 10.0 min | 5.40±0.20 | 16.60 | 33.80 | 561.08 | 1100±25% | 1300±25% | 3.58 |
| EE13.4/6/6 | 1 | 13.4±0.35 | 6.2±0.20 | 6.25±0.15 | 2.8±0.15 | 10.3 min | 4.7±0.20 | 17.50 | 31.10 | 549.20 | 1100±25% | 1300±25% | 3.40 |
| EE13.5/6/6 | 1 | 13.5±0.30 | 6.25±0.20 | 6.1±0.20 | 2.7±0.20 | 10.4 min | 4.90±0.20 | 16.50 | 31.90 | 526.35 | 1100±25% | 1300±25% | 3.20 |
| EE13.5/7/6 | 1 | 13.5±0.30 | 6.50±0.20 | 6.1±0.20 | 2.7±0.20 | 10.4 min | 5.10±0.20 | 16.50 | 32.70 | 539.55 | 1100±25% | 1300±25% | 3.25 |
| EE13.5/7/10 | 1 | 13.5±0.30 | 6.50±0.20 | 9.8±0.20 | 2.7±0.20 | 10.4 min | 5.10±0.20 | 27.30 | 32.90 | 898.17 | 1800±25% | 2100±25% | 5.30 |
| EE14/8.3/9.8 | 1 | 14.0±0.30 | 8.30±0.20 | 9.80±0.20 | 3.60±0.20 | 10.3 min | 6.40±0.20 | 34.94 | 38.27 | 1337.20 | 1950±25% | 2750±25% | 7.64 |
| EE15/7.5/12 | 1 | 15.0±0.40 | 7.50±0.20 | 12.0±0.30 | 3.50±0.20 | 11.8±0.4 | 5.80±0.20 | 40.27 | 36.75 | 1479.92 | 2500±25% | 3200±25% | 9.20 |
| EE15.5/6.45/13 | 1 | 15.55±0.35 | 6.45±0.20 | 13.2±0.25 | 4.0±0.20 | 10.95 min | 4.35±0.20 | 55.90 | 30.67 | 1714.45 | - | 4000±25% | 9.76 |
| EE16/7/5D | 1 | 16.2±0.40 | 7.4±0.20 | 4.8±0.20 | 4.0±0.20 | 11.8 min | 5.40±0.20 | 19.20 | 36.00 | 691.20 | 1100±25% | 1300±25% | 3.90 |
| EE16/7/7D | 1 | 16.2±0.40 | 7.4±0.20 | 6.8±0.20 | 4.0±0.20 | 11.8 min | 5.40±0.20 | 27.40 | 36.20 | 991.88 | 1600±25% | 2000±25% | 5.85 |
| EE16/7/8D | 1 | 16.2±0.40 | 7.4±0.20 | 8.0±0.20 | 4.0±0.20 | 11.8 min | 5.40±0.20 | 32.00 | 36.10 | 1155.20 | 1800±25% | 2200±25% | 6.70 |
| EE16/7/10D | 1 | 16.2±0.40 | 7.4±0.20 | 9.8±0.20 | 4.0±0.20 | 11.8 min | 5.40±0.20 | 40.00 | 36.08 | 1443.20 | 2000±25% | 2600±25% | 9.00 |
| EE16.5/7.4/4.8 | 1 | 16.5±0.40 | 7.4±0.20 | 4.8±0.20 | 4.0±0.20 | 12.5 min | 5.40±0.20 | 18.37 | 36.77 | 675.50 | 960±25% | 1200±25% | 4.00 |
| EE16.4/7/8 | 1 | 16.55max | 6.9±0.20 | 8.0±0.20 | 4.0±0.20 | 12.3 min | 4.90±0.20 | 31.60 | 34.30 | 1083.88 | 1900±25% | 2400±25% | 6.38 |
| EE16/7/6.8C | 1 | 16.0±0.30 | 7.2±0.20 | 6.8±0.20 | 3.2±0.20 | 12.50 min | 5.50±0.15 | 22.20 | 36.76 | 816.07 | 1000±25% | 1200±25% | 4.60 |
| EE16/7/5-2 | 1 | 16.0±0.3 | 7.2±0.15 | 4.8±0.20 | 4.0±0.20 | 12.0±0.3 | 5.20±0.20 | 18.50 | 35.50 | 656.75 | 1100±25% | 1300±25% | 4.00 |
| EE16/13/8-2 | 1 | 16.0±0.3 | 6.5±0.15 | 8.0±0.20 | 4.0±0.20 | 12.0±0.3 | 4.50±0.20 | 32.00 | 32.30 | 1034.00 | 2050±25% | 2650±25% | 6.70 |
| EE16.2/6/8.9A | 1 | 16.2±0.40 | 5.55±0.20 | 8.9±0.20 | 4.2±0.20 | 12.50 min | 3.55±0.20 | 36.00 | 27.90 | 1004.40 | 3120±25% | 4350±25% | 6.00 |
| EE16.3/6.8/9.8 | 1 | 16.3±0.3 | 6.8±0.20 | 9.8±0.25 | 4.0±0.20 | 12.6 min | 4.80±0.20 | 36.90 | 33.96 | 1253.20 | 2400±25% | 3100±25% | 7.56 |
| EE16.5/7.4/4.8 | 1 | 16.5±0.3 | 7.4±0.20 | 4.8±0.25 | 4.0±0.20 | 12.5 min | 5.40±0.20 | 19.20 | 37.33 | 716.74 | 1100±25% | 1250±25% | 4.00 |
| EE16.5/7.85/9.6 | 1 | 16.5±0.3 | 7.85±0.20 | 9.6±0.25 | 3.8±0.20 | 12.7±0.30 | 5.85±0.20 | 37.04 | 38.41 | 1422.70 | 2200±25% | 2800±25% | 8.00 |
| EE16.6/6/8 | 1 | 16.7±0.30 | 5.90±0.15 | 7.8±0.20 | 4.0±0.15 | 12.9±0.30 | 4.00±0.15 | 30.08 | 30.50 | 917.44 | 1800±25% | 2200±25% | 5.50 |
| EEL16/12/5 | 1 | 16.0±0.40 | 12.4±0.20 | 4.8±0.20 | 4.0±0.20 | 11.7 min | 10.20±0.20 | 19.10 | 55.40 | 1058.14 | 850±25% | 1050±25% | 6.56 |
| EEL16/12/1.8-1 | 1 | 16.0±0.50 | 12.0±0.30 | 1.8±0.20 | 7.0±0.20 | 12.4 min | 10.40±0.30 | 6.61 | 48.06 | 317.70 | 800±25% | 1000±25% | 2.80 |
| EEL17/12/5 | 1 | 17.2±0.30 | 12.5±0.20 | 4.85±0.20 | 4.0±0.20 | 12.8 min | 10.30±0.20 | 19.90 | 56.90 | 1132.31 | 800±25% | 1100±25% | 6.90 |
| EE17/7/5 | 1 | 16.7±0.40 | 7.4±0.20 | 4.8±0.20 | 4.0±0.20 | 12.5 min | 5.4±0.20 | 19.20 | 37.33 | 716.74 | 1100±25% | 1300±25% | 3.80 |
| EE17/8/5 | 1 | 16.8±0.40 | 7.8±0.20 | 4.8±0.20 | 4.0±0.20 | 12.5 min | 5.8±0.20 | 19.03 | 38.34 | 729.61 | 1000±25% | 1250±25% | 3.80 |
| EE17/7/6.8 | 1 | 16.7±0.40 | 7.4±0.20 | 6.8±0.20 | 4.0±0.20 | 12.5 min | 5.4±0.20 | 27.10 | 37.30 | 1010.83 | 1500±25% | 1800±25% | 5.40 |
| EE17/7/9.8 | 1 | 16.7±0.40 | 7.4±0.20 | 9.8±0.20 | 4.0±0.20 | 12.5 min | 5.4±0.20 | 38.80 | 36.64 | 1421.63 | 2200±25% | 2800±25% | 8.00 |
| EE17/8/12.5 | 1 | 16.7±0.40 | 7.8±0.20 | 12.5±0.20 | 4.0±0.20 | 12.5 min | 5.8±0.20 | 49.50 | 38.35 | 1898.33 | 2800±25% | 3200±25% | 10.70 |
| EE17/10/9.7C | 1 | 17.00±0.40 | 10.2±0.25 | 9.7±0.30 | 4.0±0.25 | 12.50 min | 8.2±0.20 | 38.41 | 47.86 | 1838.30 | 2000±25% | 2600±25% | 10.46 |
| EE17.2/8/9.8 | 1 | 17.20±0.40 | 7.8±0.20 | 9.8±0.20 | 4.0±0.20 | 12.70 min | 5.8±0.20 | 39.50 | 38.65 | 1526.68 | 2200±25% | 2800±25% | 8.50 |
| EE17.2/8/12.6 | 1 | 17.20±0.40 | 7.8±0.20 | 12.6±0.20 | 4.0±0.20 | 12.70 min | 5.8±0.20 | 50.80 | 38.65 | 1963.42 | 2900±25% | 3300±25% | 11.12 |
| EE17.4/7/6.8 | 1 | 17.40±0.40 | 7.5±0.20 | 6.8±0.20 | 4.0±0.20 | 13.10 min | 5.5±0.20 | 26.70 | 39.00 | 1041.30 | 1500±25% | 1700±25% | 5.54 |
| EE17.4/7/7.3 | 1 | 17.40±0.40 | 7.5±0.20 | 7.3±0.20 | 4.0±0.20 | 13.10 min | 5.5±0.20 | 28.80 | 37.80 | 1088.64 | 1600±25% | 1800±25% | 5.92 |
| EE17.4/8/9.8 | 1 | 17.40±0.40 | 7.9±0.20 | 9.8±0.20 | 4.0±0.20 | 13.10 min | 5.90±0.20 | 38.70 | 39.30 | 1520.91 | 2000±25% | 2600±25% | 8.10 |
| EE17.4/8/12.6 | 1 | 17.40±0.40 | 7.8±0.20 | 12.6±0.20 | 4.0±0.20 | 13.10 min | 5.80±0.20 | 49.96 | 38.94 | 1945.5 | 3200±25% | 3800±25% | 10.80 |
| EE17.5/6/7.5 | 1 | 17.5±0.40 | 6.4±0.15 | 7.5±0.20 | 5.20±0.20 | 12.2 min | 4.0±0.15 | 38.23 | 30.70 | 1173.66 | 2000±25% | 3000±25% | 6.80 |
| EE17.5/7.7/4.8 | 1 | 17.5±0.30 | 7.9±0.20 | 4.8±0.20 | 6.00±0.20 | 12.5 min | 5.9±0.20 | 22.54 | 36.23 | 816.60 | 1200±25% | 1500±25% | 5.14 |
| EE17.8/8.5/10 | 1 | 17.8±0.30 | 8.5±0.15 | 9.8±0.20 | 4.2±0.20 | 13.0 min | 6.4±0.15 | 41.16 | 41.38 | 1742.00 | 2150±25% | 2800±25% | 9.80 |
| EE18.4/6/7.4 | 1 | 18.4±0.40 | 6.2±0.20 | 7.4±0.20 | 5.50±0.20 | 12.7 min | 3.7±0.15 | 39.50 | 30.40 | 1200.80 | 2000±25% | 2900±25% | 7.05 |
| EF16/6/5 | 1 | 16.1±0.30 | 6.1±0.20 | 4.5±0.20 | 4.5±0.20 | 11.7 min | 4.0±0.20 | 19.30 | 30.20 | 582.86 | 1100±25% | 1600±25% | 3.20 |
| EF16/6/7 | 1 | 16.1±0.30 | 5.75±0.15 | 7.15±0.20 | 4.5±0.20 | 11.7 min | 3.7±0.15 | 31.30 | 27.88 | 872.64 | 2300±25% | 2500±25% | 5.16 |
| EF16.5/8/5 | 1 | 16.5±0.40 | 8.2±0.20 | 4.5±0.20 | 4.55±0.20 | 11.7 min | 5.9±0.20 | 19.90 | 38.20 | 760.18 | 1200±25% | 1450±25% | 4.06 |
| EF16.5/6/8 | 1 | 16.5±0.40 | 6.1±0.20 | 8.0±0.20 | 4.55±0.20 | 11.7 min | 4.0±0.20 | 34.50 | 30.40 | 1048.80 | 2100±25% | 3000±25% | 7.30 |
| EF16.6/6/8 | 1 | 16.6±0.40 | 6.0±0.20 | 8.0±0.20 | 4.55±0.20 | 12.0 min | 4.0±0.20 | 33.30 | 30.45 | 1013.99 | 2200±25% | 3000±25% | 5.86 |
| EF17.5/8/8.4 | 1 | 17.5±0.40 | 7.5±0.20 | 8.4±0.20 | 4.55±0.20 | 12.4 min | 5.5±0.20 | 36.70 | 36.90 | 1354.23 | 2300±25% | 3200±25% | 8.35 |
| EF18.1/6/12 | 1 | 18.1±0.30 | 6.0±0.20 | 11.9±0.2 | 4.60±0.20 | 13.3 min | 3.70±0.15 | 54.74 | 30.93 | 1692.89 | - | - | 10.20 |
| EE18.8/8/9.2 | 1 | 18.8±0.40 | 7.8±0.20 | 9.2±0.20 | 5.10±0.20 | 12.8 min | 5.0±0.20 | 36.70 | 36.90 | 1354.23 | 2300±25% | 3200±25% | 8.35 |
| EE19/8/5 | 1 | 19.2±0.40 | 8.1±0.20 | 4.85±0.20 | 4.60±0.20 | 14.1 min | 5.8±0.20 | 22.10 | 40.20 | 888.42 | 1200±25% | 1400±25% | 5.10 |
| EE19/8/10 | 1 | 19.2±0.40 | 8.1±0.20 | 9.6±0.20 | 4.60±0.20 | 14.1 min | 5.8±0.20 | 45.40 | 40.00 | 1816.00 | 2000±25% | 3000±25% | 10.60 |
| EE19/8/5A | 1 | 19.1±0.40 | 9.0±0.20 | 4.9±0.20 | 4.70±0.20 | 14.2 min | 6.7±0.20 | 22.53 | 43.90 | 989.30 | 1200±25% | 1400±25% | 5.50 |
| EE19/8/5D | 1 | 19.5±0.40 | 8.3±0.20 | 5.0±0.20 | 4.85±0.20 | 14.0 min | 5.8±0.20 | 25.00 | 40.50 | 1012.50 | 1300±25% | 1500±25% | 5.65 |
| EE19/8/5E | 1 | 19.1±0.30 | 8.1±0.20 | 4.85±0.20 | 4.85±0.20 | 14.2 min | 5.8±0.20 | 23.30 | 39.20 | 913.00 | 1300±25% | 1500±25% | 5.60 |
| EEL19/11.5/5 | 1 | 19.2±0.40 | 11.5±0.3 | 4.85±0.25 | 4.60±0.25 | 14.0 min | 9.00±0.30 | 25.00 | 57.05 | 1426.35 | - | 1300±25% | 6.86 |
| EEL19/14/5 | 1 | 20.2±0.40 | 13.8±0.30 | 5.0±0.25 | 5.0±0.25 | 14.8 min | 11.3±0.30 | 24.10 | 63.00 | 1518.30 | 1000±25% | 1200±25% | 9.20 |
| EE19.5/7.75/12.5 | 1 | 19.5±0.40 | 7.75±0.20 | 12.50±0.30 | 5.30±0.30 | 14.0 min | 5.00±0.20 | 67.11 | 37.27 | 2501.40 | - | 7400±25% | 15.90 |
| EE19.8/8/4.8 | 1 | 19.8±0.40 | 8.3±0.30 | 4.8±0.25 | 4.85±0.25 | 15.2 min | 5.9±0.30 | 22.01 | 41.51 | 913.49 | 1200±25% | 1500±25% | 5.40 |
| EE19.9/8/10.1 | 1 | 19.9±0.40 | 8.30±0.20 | 10.1±0.20 | 5.05±0.20 | 14.5 min | 5.7±0.20 | 51.30 | 40.70 | 2087.91 | 3000±25% | 3800±25% | 12.20 |
| EE19.9/8/12.1 | 1 | 19.9±0.40 | 8.30±0.20 | 12.1±0.20 | 5.05±0.20 | 14.5 min | 5.7±0.20 | 61.50 | 40.70 | 2503.05 | 3700±25% | 4600±25% | 14.60 |
| EE20/8/5 | 1 | 20.2±0.40 | 8.10±0.20 | 4.8±0.20 | 4.8±0.20 | 15.0 min | 5.8±0.20 | 22.98 | 41.02 | 942.64 | 1150±25% | 1500±25% | 5.54 |
| EE20.5/10.7/7 | 1 | 20.5±0.70 | 10.95±0.20 | 7.0±0.20 | 5.0±0.20 | 14.0 min | 7.35±0.20 | 38.80 | 48.50 | 1881.80 | 1800±25% | 2400±25% | 11.10 |
| EF20/10/6 | 1 | 20.0±0.40 | 10.1±0.20 | 5.7±0.20 | 5.7±0.20 | 14.1 min | 7.2±0.20 | 32.20 | 46.50 | 1497.30 | 1500±25% | 2000±25% | 8.40 |
| EF20/10/9 | 1 | 20.0±0.40 | 9.9±0.20 | 8.8±0.20 | 5.7±0.20 | 14.1 min | 7.2±0.20 | 50.10 | 46.00 | 2304.60 | 2500±25% | 3200±25% | 13.00 |
| EF20/10/11 | 1 | 20.0±0.40 | 9.9±0.20 | 10.75±0.25 | 5.7±0.20 | 14.1 min | 7.2±0.20 | 61.50 | 46.00 | 2829.00 | 3000±25% | 3800±25% | 15.70 |
| EF20/10.5/6F | 1 | 20.4±0.40 | 10.5±0.20 | 5.70±0.20 | 5.7±0.20 | 14.6 min | 7.8±0.20 | 31.67 | 49.12 | 1515.70 | 1450±25% | 1950±25% | 8.55 |
| EF20/10.75/10.6B | 1 | 20.0±0.40 | 10.75±0.20 | 10.60±0.25 | 5.7±0.20 | 14.1 min | 7.6±0.20 | 61.10 | 48.40 | 2957.24 | 2800±25% | 3600±25% | 16.80 |
| EF20/10/18 | 1 | 20.0±0.40 | 10.4±0.20 | 17.60±0.30 | 5.7±0.20 | 14.1 min | 7.6±0.20 | 98.50 | 48.00 | 4728.00 | 4800±25% | 5400±25% | 26.00 |
| EF20/10/6E | 1 | 20.1±0.40 | 10.0±0.20 | 5.70±0.20 | 5.7±0.20 | 14.7 min | 7.4±0.20 | 30.10 | 47.15 | 1419.22 | 1500±25% | 2000±25% | 8.26 |
| EF20/10/11E | 1 | 20.1±0.40 | 10.0±0.20 | 11.0±0.20 | 5.7±0.20 | 14.3 min | 7.3±0.20 | 60.00 | 46.80 | 2808.00 | 3000±25% | 3700±25% | 15.60 |
| EF20/07/16 | 1 | 20.15±0.40 | 7.40±0.20 | 16.0±0.25 | 5.7±0.20 | 14.4 min | 4.5±0.20 | 91.20 | 36.20 | 3302.20 | 4700±25% | 6000±25% | 19.60 |
| EF20.4/7.75/15.8 | 1 | 20.4±0.40 | 7.75±0.20 | 15.8±0.25 | 5.7±0.20 | 14.5 min | 4.7±0.20 | 91.10 | 37.10 | 3379.81 | 4000±25% | 6600±25% | 20.40 |
| EF21/10/6 | 1 | 21.0±0.40 | 10.25±0.20 | 5.7±0.20 | 5.7±0.20 | 15.1 min | 7.5±0.20 | 31.20 | 48.20 | 1503.84 | 1400±25% | 2000±25% | 8.26 |
| EF21/9/11 | 1 | 21.0±0.50 | 9.00±0.20 | 10.75±0.25 | 5.7±0.20 | 15.1 min | 6.2±0.20 | 57.40 | 43.50 | 2496.90 | 3200±25% | 4200±25% | 14.20 |
| EE21.6/11/5 | 1 | 21.6±0.50 | 10.7±0.15 | 4.8±0.20 | 4.8±0.15 | 16.6±0.35 | 8.4±0.15 | 23.05 | 52.81 | 1217.30 | 1100±25% | 1300±25% | 6.96 |
| EE22/9/14 | 1 | 22.0±0.50 | 9.00±0.20 | 14.0±0.30 | 5.0±0.25 | 16.7 min | 6.5±0.20 | 69.04 | 45.96 | 3173.10 | 3600±25% | 4700±25% | 18.10 |
| EE22/10/6C | 1 | 22.0±0.40 | 9.4±0.25 | 5.75±0.20 | 5.75±0.20 | 16.0±0.40 | 5.6±0.25 | 36.30 | 42.80 | 1553.64 | 1800±25% | 2400±25% | 9.14 |
| EE22/10/8.7 | 1 | 22.3±0.40 | 9.5±0.25 | 8.70±0.20 | 5.75±0.20 | 15.9 min | 5.6±0.25 | 54.60 | 43.15 | 2355.99 | 2800±25% | 3600±25% | 13.90 |
| EE22/10/6B | 1 | 22.3±0.40 | 9.4±0.25 | 5.75±0.20 | 5.70±0.20 | 16.20 min | 5.6±0.25 | 35.50 | 43.10 | 1530.05 | 1800±25% | 2400±25% | 9.14 |
| EE22/10/8.7B | 1 | 22.3±0.40 | 9.5±0.25 | 8.70±0.20 | 5.70±0.20 | 16.20 min | 5.6±0.25 | 54.30 | 43.20 | 2345.76 | 2200±25% | 3600±25% | 14.10 |
| EE22/9/11 | 1 | 22.0±0.40 | 8.85±0.20 | 10.90±0.20 | 6.40±0.20 | 16.00 min | 6.0±0.20 | 63.90 | 43.10 | 2754.09 | 3000±25% | 3800±25% | 15.60 |
| EE22/13/8D | 1 | 22.0±0.40 | 12.8±0.20 | 8.00±0.20 | 5.50±0.20 | 16.60 min | 9.80±0.20 | 43.20 | 59.30 | 2561.76 | 2000±25% | 2500±25% | 14.26 |
| EEL22/13/6-1 | 1 | 22.0±0.40 | 12.60±0.20 | 5.75±0.20 | 5.75±0.20 | 15.60 min | 9.0±0.20 | 35.83 | 56.25 | 2015.44 | 1600±25% | 2000±25% | 12.50 |
| EEL22/15/6 | 1 | 22.2±0.40 | 15.35±0.20 | 5.75±0.20 | 5.75±0.20 | 15.90 min | 11.35±0.20 | 34.30 | 66.00 | 2263.80 | 1200±25% | 1500±25% | 14.50 |
| EE22.5/9/11 | 1 | 22.5±0.40 | 8.90±0.20 | 10.9±0.20 | 5.70±0.20 | 16.20 min | 6.00±0.20 | 59.00 | 45.00 | 2655.00 | 2000±25% | 2800±25% | 16.00 |
| EE25.5/10/6.4 | 1 | 25.5±0.40 | 10.3±0.20 | 6.40±0.20 | 6.40±0.20 | 19.4±0.20 | 6.90±0.20 | 41.12 | 50.77 | 2087.54 | - | - | 11.76 |
| EE23/9/8.7E | 1 | 22.9±0.40 | 9.0±0.20 | 8.70±0.20 | 5.70±0.20 | 17.50min | 5.6±0.20 | 49.95 | 43.70 | 2182.82 | 2600±25% | 3800±25% | 13.10 |
| EE23/10/6 | 1 | 22.9±0.40 | 9.6±0.20 | 6.00±0.20 | 6.10±0.20 | 15.70 min | 5.8±0.20 | 39.50 | 44.00 | 1738.00 | 1900±25% | 2300±25% | 9.90 |
| EE23/9.6/5.75F | 1 | 23.0±0.40 | 9.6±0.20 | 5.75±0.20 | 5.80±0.20 | 16.80 min | 5.9±0.20 | 35.97 | 44.95 | 1616.85 | 1900±25% | 2300±25% | 9.50 |
| EF23/11.75/5.7 | 1 | 23.0±0.40 | 11.75±0.20 | 5.70±0.20 | 5.70±0.20 | 17.30 min | 9.0±0.20 | 31.74 | 56.50 | 1793.40 | 1400±25% | 1600±25% | 10.10 |
| EE23/8.5/10.75 | 1 | 23.45±0.45 | 8.50±0.20 | 10.75±0.25 | 7.20±0.20 | 17.40 min | 5.0±0.20 | 72.00 | 41.30 | 2975.50 | 3500±25% | 4700±25% | 17.12 |
| EE23.3/9.4/10 | 1 | 23.3±0.40 | 9.4±0.20 | 5.75±0.20 | 5.75±0.20 | 17.00 min | 6.0±0.20 | 35.23 | 45.37 | 1598.39 | 1900±25% | 2300±25% | 9.30 |
| EE23.5/10.5/11 | 1 | 23.5±0.40 | 10.50±0.20 | 11.00±0.20 | 6.70±0.20 | 16.30 min | 7.10±0.20 | 73.65 | 49.16 | 3620.63 | 3500±25% | 4200±25% | 20.70 |
| EE23.5/12/11 | 1 | 23.5±0.40 | 12.00±0.20 | 11.00±0.20 | 7.80±0.20 | 16.30 min | 7.10±0.20 | 84.83 | 49.90 | 4233.50 | 3500±25% | 4400±25% | 25.40 |
| EE24/9/8.2 | 1 | 24.0±0.40 | 9.30±0.20 | 8.20±0.20 | 7.20±0.20 | 17.60 min | 5.70±0.20 | 55.20 | 44.15 | 2437.10 | 2600±25% | 3500±25% | 14.50 |
| EE24.5/9.4/12 | 1 | 24.5±0.50 | 9.40±0.20 | 12.0±0.30 | 6.00±0.20 | 18.30 min | 6.50±0.20 | 69.80 | 48.00 | 3350.40 | 3400±25% | 4600±25% | 19.40 |
| EE25/10/6 | 1 | 25.4±0.50 | 10.0±0.20 | 6.4±0.20 | 6.35±0.20 | 18.55 min | 6.9±0.20 | 40.00 | 49.70 | 1988.00 | 1800±25% | 2600±25% | 11.50 |
| EE25/10/6-1 | 1 | 25.4±0.40 | 9.95±0.15 | 6.35±0.20 | 6.35±0.20 | 19.0±0.40 | 6.75±0.15 | 40.40 | 48.00 | 1939.00 | 1800±25% | 2600±25% | 11.60 |
| EEL25/16/6 | 1 | 25.6±0.40 | 16.1±0.25 | 6.35±0.30 | 6.35±0.30 | 19.0±0.50 | 13.1±0.25 | 39.90 | 74.70 | 2980.53 | 1350±25% | 1800±25% | 18.00 |
| EF25/19/9.4 | 1 | 24.9±0.50 | 9.5±0.20 | 9.4±0.25 | 7.20±0.25 | 17.40 min | 5.9±0.20 | 67.68 | 45.41 | 3073.35 | 3200±25% | 4200±25% | 17.60 |
| EF25/13/7 | 1 | 25.05±0.75 | 12.55±0.25 | 7.20±0.30 | 7.25±0.25 | 17.50 min | 8.95±0.25 | 51.90 | 57.90 | 3005.01 | 2000±25% | 2700±25% | 16.50 |
| EF25/13/9 | 1 | 25.05±0.75 | 12.55±0.25 | 8.85±0.25 | 7.25±0.25 | 17.50 min | 8.95±0.25 | 63.40 | 57.90 | 3670.86 | 2500±25% | 3100±25% | 20.20 |
| EF25/13/11 | 1 | 25.05±0.75 | 12.55±0.25 | 10.75±0.25 | 7.25±0.25 | 17.50 min | 8.95±0.25 | 76.00 | 58.60 | 4453.60 | 3000±25% | 3800±25% | 24.56 |
| EF25/07/15 | 1 | 25.05±0.40 | 7.40±0.20 | 15.05±0.25 | 7.25±0.25 | 17.60 min | 3.95±0.20 | 106.34 | 37.51 | 3988.81 | 6200±25% | 8000±25% | 23.50 |
| EF25/8.4/12.8B | 1 | 25.20±0.60 | 8.40±0.20 | 12.80±0.30 | 7.00±0.25 | 17.90 min | 4.90±0.25 | 87.44 | 41.49 | 3627.89 | 4600±25% | 5500±25% | 21.70 |
| EF25.5/13/7 | 1 | 25.50±0.50 | 12.70±0.20 | 7.20±0.20 | 7.20±0.20 | 18.40 min | 9.10±0.20 | 50.15 | 59.10 | 2963.87 | 2000±25% | 2700±25% | 16.40 |
| EF25.8/8.7/12.8B-1 | 1 | 25.80±0.40 | 8.65±0.20 | 12.80±0.25 | 7.07±0.20 | 18.40 min | 5.00±0.20 | 91.10 | 43.02 | 3919.03 | - | 6200±25% | 22.98 |
| EF26/7/11 | 1 | 26.2±0.4 | 7.00±0.15 | 10.75±0.30 | 7.25±0.20 | 19.0±0.30 | 3.6±0.15 | 75.25 | 37.43 | 2816.61 | 3000±25% | 4000±25% | 17.00 |
| EF26/13/7 | 1 | 26.0±0.5 | 13.0±0.20 | 7.20±0.30 | 7.20±0.20 | 19.50 min | 9.5±0.20 | 47.80 | 61.10 | 2920.58 | 1850±25% | 2300±25% | 16.70 |
| EF27/13/7 | 1 | 27.0±0.5 | 12.7±0.30 | 7.20±0.30 | 7.20±0.20 | 19.60 min | 9.1±0.20 | 51.59 | 60.37 | 3114.39 | 1900±25% | 2500±25% | 17.30 |
| EE28/10/11 | 1 | 28.0±0.6 | 10.75±0.25 | 10.50±0.20 | 7.20±0.30 | 18.60 min | 6.65±0.25 | 83.10 | 51.30 | 4300.00 | 3600±25% | 4400±25% | 24.70 |
| EE28.5/10/11 | 1 | 28.5±0.5 | 10.40±0.25 | 10.70±0.20 | 7.25±0.30 | 20.00 min | 6.40±0.25 | 81.00 | 51.50 | 4171.50 | 3800±25% | 4600±25% | 22.10 |
| EE29.6/9.9/12.3 | 1 | 29.6±0.4 | 9.90±0.20 | 12.30±0.25 | 7.30±0.20 | 20.50 min | 6.40±0.20 | 92.42 | 50.63 | 4679.40 | 4900±25% | - | 27.00 |
| EE30/15/7A | 1 | 30.0±0.5 | 15.0±0.20 | 7.05±0.20 | 6.95±0.20 | 19.50 min | 10.00±0.25 | 59.20 | 65.70 | 3889.44 | 2400±25% | 2900±25% | 23.70 |
| EE30/13/11 | 1 | 30.0±0.6 | 13.25±0.25 | 10.60±0.20 | 10.60±0.20 | 19.80 min | 8.60±0.25 | 104.00 | 59.30 | 6167.20 | 3500±25% | 4300±25% | 34.40 |
| EE30/12/6.7-1 | 1 | 30.0±0.5 | 11.50±0.15 | 6.70±0.20 | 6.70±0.20 | 21.0±0.50 | 6.75±0.15 | 54.60 | 53.80 | 2937.48 | 2300±25% | 2900±25% | 17.60 |
| EE31/13/9 | 1 | 30.9±0.60 | 13.4±0.20 | 9.4±0.30 | 9.4±0.30 | 21.9 min | 8.90±0.3 | 84.40 | 62.60 | 5280.00 | 2950±25% | 3600±25% | 29.80 |
| EE30.5/7/14 | 1 | 30.5±0.40 | 6.95±0.20 | 14.0±0.30 | 4.90±0.20 | 25.5±0.40 | 4.40±0.20 | 70.39 | 46.08 | 3243.78 | 3000±25% | - | 18.90 |
| EE32/16.3/44 | 1 | 32.0±0.80 | 16.3±0.20 | 44.0±0.30 | 6.0±0.30 | 25.5+0.50 | 10.5±0.20 | 359.56 | 64.45 | 23173.64 | - | - | 171.60 |
| EE33/15/13 | 1 | 33.0±0.80 | 14.8±0.20 | 12.7±0.30 | 9.8±0.30 | 23.7 min | 10.0±0.20 | 115.10 | 69.20 | 7965.40 | 3700±25% | 4500±25% | 43.80 |
| EE33.5/16.5/18 | 1 | 33.5±0.80 | 16.5±0.20 | 18.0±0.30 | 7.0±0.20 | 23.0 min | 13.0±0.20 | 126.00 | 79.50 | 10017.00 | - | 5200±25% | 54.70 |
| EE35/14.4/9.5 | 1 | 34.9±0.70 | 14.45±0.20 | 9.50±0.30 | 9.4±0.30 | 25.40 min | 9.80±0.20 | 87.30 | 70.30 | 6137.19 | 3300±25% | 4100±25% | 33.60 |
| EE35.8/7/14 | 1 | 35.8±0.40 | 6.95±0.20 | 14.0±0.20 | 5.4±0.20 | 30.4±0.4 | 4.20±0.15 | 76.30 | 52.25 | 3986.68 | 3600±25% | - | 22.26 |
| EE42/21/15 | 1 | 42.0±0.50 | 21.2±0.25 | 15.0±0.30 | 12.0±0.30 | 29.5 min | 15.4±0.25 | 177.00 | 98.30 | 17399.10 | 4000±25% | 6000±25% | 94.50 |
| EE42/21/20 | 1 | 42.0±0.50 | 21.2±0.25 | 20.0±0.30 | 12.0±0.30 | 29.5 min | 15.4±0.25 | 236.20 | 98.30 | 23218.46 | 6300±25% | 7700±25% | 129.00 |
| EE42/7/16.5B | 1 | 42.0±0.60 | 6.80±0.20 | 16.5±0.30 | 4.8±0.20 | 37.00 min | 4.50±0.20 | 77.10 | 57.80 | 4456.38 | 2800±25% | 3500±25% | 29.50 |
| EE42/7/24A | 1 | 42.0±0.60 | 6.80±0.20 | 24.0±0.30 | 6.0±0.20 | 35.40 min | 3.80±0.20 | 144.00 | 54.60 | 7862.40 | 6200±25% | 8000±25% | 48.80 |
| EE42.5/8/16.5 | 1 | 42.5±0.60 | 7.50±0.20 | 16.5±0.35 | 4.8±0.20 | 37.00 min | 5.20±0.20 | 77.46 | 60.98 | 4723.80 | 2800±25% | 3500±25% | 28.60 |
| EE42.5/22/20 | 1 | 42.5±0.50 | 21.5±0.25 | 20.0±0.40 | 12.0±0.30 | 30.0 min | 15.45±0.25 | 240.50 | 99.30 | 23881.65 | 6300±25% | 7700±25% | 130.70 |
| EE42.5/22/25 | 1 | 42.5±0.50 | 21.5±0.25 | 24.8±0.40 | 12.0±0.30 | 30.0 min | 15.45±0.25 | 298.60 | 99.30 | 29650.98 | 7200±25% | 9000±25% | 162.00 |
| EE44/7.15/16 | 1 | 44.0±0.50 | 7.15±0.15 | 16.0±0.30 | 6.00±0.25 | 38.0±0.5 | 4.45±0.15 | 89.65 | 58.63 | 5255.91 | 3100±25% | - | 31.20 |
| EE50/6/16.5 | 1 | 50.0±0.60 | 6.45±0.15 | 16.50±0.30 | 5.60±0.2 | 43.40 min | 3.70±0.15 | 92.50 | 62.25 | 5758.13 | 3500±25% | 4400±25% | 37.55 |
| EE50/8/20.3D | 1 | 50.0±0.50 | 7.70±0.15 | 20.30±0.30 | 6.50±0.2 | 43.00 min | 4.80±0.15 | 122.30 | 65.70 | 8035.11 | 3800±25% | 4800±25% | 51.00 |
| EE50/21.5/15 | 1 | 50.0±0.70 | 21.5±0.15 | 15.0±0.35 | 14.6±0.35 | 34.20 min | 12.95±0.25 | 233.12 | 96.82 | 22570.68 | 5000±25% | 7700±25% | 127.60 |
| EE50/27/15 | 1 | 50.0±0.70 | 27.2±0.20 | 14.60±0.30 | 14.60±0.3 | 34.10 min | 18.60±0.20 | 225.20 | 119.50 | 26911.40 | 5000±25% | 6000±25% | 147.30 |
| EE51.3/14.4/23.8 | 1 | 51.3±0.80 | 14.4±0.20 | 23.8±0.40 | 15.0±0.3 | 36.9±0.8 | 7.20±0.20 | 346.40 | 73.50 | 25460.40 | 12000±25% | 14800±25% | 146.00 |
| EE55/28/21 | 1 | 55.0±1.00 | 27.5±0.30 | 20.75±0.3 | 16.95±0.35 | 38.5±1.0 | 18.9±0.4 | 349.00 | 124.00 | 43200.00 | 6000±25% | 8500±25% | 236.60 |
| EE55/28/25 | 1 | 55.0±1.00 | 27.5±0.30 | 24.7±0.30 | 16.95±0.35 | 38.5±1.0 | 18.9±0.4 | 420.00 | 124.00 | 52100.00 | 7000±25% | 10000±25% | 280.40 |
| EE55/28.5/21S | 1 | 55.15±1.05 | 28.5±0.30 | 20.60±0.40 | 16.95±0.35 | 38.5±1.0 | 19.9±0.4 | 347.85 | 127.87 | 44479.58 | 7000±25% | - | 242.80 |
| EE56.5/28.2/20.6 | 1 | 56.50±1.00 | 28.2±0.30 | 20.60±0.30 | 16.85±0.30 | 38.5±1.0 | 19.4±0.4 | 359.45 | 126.66 | 45528.96 | 5800±25% | 8000±25% | 241.20 |
| EE56.5/28.2/20.6E | 1 | 56.50±1.00 | 28.2±0.30 | 20.60±0.30 | 16.85±0.30 | 40.2±1.0 | 19.4±0.4 | 359.45 | 126.66 | 45528.96 | 5800±25% | 8000±25% | 241.40 |
| EE60/4.5/50 | 1 | 60.3±0.70 | 4.50±0.15 | 50.0±0.50 | 10.0±0.30 | 52.3±0.7 | 2.0±0.15 | 270.60 | 59.50 | 16100.70 | - | 1400±25% | 114.00 |
| EE60/5.7/50 | 1 | 60.3±0.70 | 5.70±0.15 | 50.0±0.50 | 10.0±0.30 | 52.3±0.7 | 3.0±0.15 | 295.00 | 63.50 | 18732.50 | - | 1450±25% | 126.80 |
| EE65/33/27 | 1 | 65.1±1.40 | 32.5±0.30 | 26.9±0.50 | 19.65±0.35 | 44.2 min | 22.6±0.4 | 535.00 | 147.00 | 78600.00 | 8500±25% | 11500±25% | 419.00 |
| EE70/33/32 | 1 | 70.5±1.20 | 32.95±0.30 | 31.6±0.50 | 21.65±0.35 | 48.0 min | 22.25±0.4 | 682.35 | 150.00 | 102352.5 | 10000±25% | 13500±25% | 565.00 |
| EE85/45/27 | 1 | 85.0±2.0 | 44.50±0.50 | 26.5±0.50 | 26.50±0.5 | 56.0 min | 30.50±0.5 | 717.30 | 196.50 | 140949.5 | 7800±25% | 9800±25% | 780.00 |
| EE85/45/32 | 1 | 85.0±2.0 | 44.50±0.50 | 31.5±0.50 | 26.50±0.5 | 56.0 min | 30.50±0.5 | 837.30 | 198.80 | 166455.2 | 10000±25% | 13500±25% | 925.00 |
| 注:AL值测试条件:1KHz、 0.3V、 100Ts (Remark:Testing conditon for AL:1KHz、 0.3V、 100Ts ) | |||||||||||||
| 以上为本公司标准规格，可根据客户特殊要求进行设计。(The above is the usually type，we can redesign according to costomer′s request) | |||||||||||||
