EP
EP
 |
| Fig.1 |
| Type | Fig | Dimensions(mm) | Effective parameter | AL(nH/N2) | Wt | ||||||||
| A | B | C | D | E | F | Ae(mm2) | Le(mm) | Ve(mm3) | BP40 | BP95 | (g/set) | ||
| EP7 | 1 | 9.35±0.2 | 3.85±0.15 | 6.4±0.20 | 3.3±0.20 | 7.2min | 2.75±0.15 | 10.30 | 15.70 | 162.00 | 1100±25% | 1320±25% | 2 |
| EP13 | 1 | 12.7±0.3 | 6.65±0.20 | 8.8±0.20 | 4.35±0.20 | 9.8min | 4.7±0.20 | 19.50 | 23.60 | 460.20 | 1500±25% | 1850±25% | 5.7 |
| EP17 | 1 | 18.2±0.4 | 8.70±0.20 | 11.0±0.25 | 5.70±0.20 | 12.30min | 5.85±0.20 | 34.00 | 28.00 | 953.30 | 2400±25% | 3000±25% | 14.2 |
| EP20 | 1 | 24.0±0.5 | 11.0±0.20 | 15.0±0.40 | 8.8±0.30 | 16.10min | 7.40±0.20 | 78.70 | 40.15 | 3159.81 | 4000±25% | 5000±25% | 33.1 |
Remark: Testing conditon for AL: 1KHz / 0.3V / 100Ts.
The above is the usually type，We can redesign according to costomer′s request.
